OPGW Suspension Clamp Double
LG-OPGW-SC02
Product Overview
Double Suspension Clamp For OPGW Cable RTS more than 140KN
Product Information
Product Details
Double suspension clamps are mainly used for hanging and supporting optical cables on
straight towers with high drop, large span(more than 800m), or line angles 30°~60°.
Specification
Model | LG-OPGW-SC02 (OPGW Double Suspension Clamp) |
Cable RTS | >140KN |
Cable OD | 8.5mm~18.5mm |
Clamp material | Aluminium alloy, hot-dip galvanized steel |
Rods material | Aluminium alloy, aluminum-clad steel wire |
Clamp RTS | 15%~20% of cable RTS |
Breaking strength | >100KN |
One set including | 2pcs U-Shackle, Housing, Rubber, 2pcs PS Clevis, Outer rods, Inner rods, Earth wire, Bolt & nut etc |
Note:
It is best to order ADSS cables and its supporting fittings together.
If purchased separately, please provide specifications of the ADSS cable
( outer diameter, span length, MAT, RTS/UTS, etc.), as well as the working environment,
so that we can recommend suitable models based on the data for the smooth implementation of the project.
Ordering Information
| Model | Name | Status | Action |
|---|---|---|---|
| LG-OPGW-SC02 | OPGW Suspension Clamp Double | In Stock |
